HARDWARE FEATURES
MANAGEMENT
HARDWARE FEATURES
| Interface | 2 × 10/100Mbps Ethernet Port |
| 1 × USB 2.0 Port for configuration backup | |
| 1 × Micro USB Port for power | |
| Power Supply | 802.3af/at PoE or Micro USB（DC 5V/1A） |
| Dimensions | 3.9 × 3.9 × 1.0in. (100 × 98 × 25mm) |
Â
MANAGEMENT
Omada App Yes Centralized Management Up to 100 Omada access points, 20 JetStream switches, and 10 Omada routers Up to 1,000 Clients Note Please refer to www.tp-link.com/en/business-networking/all-omada/ to find all the device models supported by OC200 Cloud Access Yes L3 Management Yes Multi-site Management Yes Management Features Automatic Device Discovery Batch Configuration Batch Firmware Upgrading Intelligent Network Monitoring Abnormal Event Warnings Unified Configuration Reboot Schedule Captive Portal Configuration
